"gridType"

"gridType" specifies whether the column and row grid lines or both of a table will be shown or not.

Synopsis

setValue(string shape, "gridType", int type);

shape.gridType( int type);

Parameters

Parameter Description
shape Name of the object.
type

0 = No lines (column & row)

1 = Row lines are shown.

2 = Column lines are shown.

The values 1 and 2 can be combined to show both row and column grid lines (see example 2 below).

Description

gridType" specifies whether the column and row grid lines of a table will be shown or not.

Figure 1. Only Row Grid Lines are shown for a Table

Example 2

In the following example, the row and the column grid lines of the table will be shown.

main()
{
  TABLE1.gridType(1|2);
}

Assignment

Table
